Jedo Heavy Duty Tubular Latches - 45 Degree Short Travel 102mm Satin Stainless Steel - By Frelan Hardware - JL-HDT102SS
- Overview
- Documentation
A heavy-duty tubular latch is a robust locking mechanism used to secure doors in high-traffic or heavy-use areas. Unlike a standard latch, it's built with stronger materials and components to withstand frequent operation and greater force. The latch fits into a cylindrical hole drilled into the edge of the door (hence "tubular"), and it's typically used in conjunction with lever handles or door knobs.
KEY FEATURES
Case Type: Heavy Duty Tubular Latch
Forend: Square (SS)
Material Grade: 201 Stainless Steel
Finish: Satin Stainless Steel
Sprung: Yes
Fire Rating: FD30/60
Certifire: Yes
BS EN 12209: Yes
UKCA / CE: Yes / Yes
Corrosion Grade: 3
Mechanical Warranty: 15 Years
Use: Internal / External (Residential / Commercial)
Suitable Door Thickness: 35–54mm
Fixings: 4 x wood screws
DIMENSIONS
Case Length: 102mm
Backset (to spindle): 45mm
To maintain compliance with the fire standard for this latch, it is recommended that you fit these with the relevant intumescent pack (GRA 16 & GRA 16.2)
Tailored quotes are available for larger commercial projects — contact our team to discuss specifications and pricing.
STANDARDS & CERTIFICATIONS
Additional Information :
• CE / UKCA : BS EN 12209
• Certifire : Yes
• Corrosion Grade : Grade 3
• Fire Rating : FD30/60
• Internal / External : Internal / External
• Material : Stainless Steel
• Material Grade : 304g Stainless Steel
• Mechanical Warranty : 15 Years
• Overall Size : 60 x 25mm x 102mm
• Size : 102mm
• Suitable Door Thickness : 35 - 54mm
